TEOS DOWNLIGHTS SERIES – T281

TEOS rectangular LED grille downlight is unique designed with COB high power LED chip.
High efficient reflector with COB LED provides high lumen output and wide beam angle. Single head, double head and triple head provided for wide choice. Adjustable lighting direction offers various lighting orientation.

Details

TEOS DOWNLIGHTS SERIES

CODE	OPTIC	LUMENS	WATTAGE	LUMENS/W	CCT	IP RATING	CRI	CONTROL	SIZE
T270	24°	460-550lm	8W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L100W100H135mm
T271	24°	1040-1250lm	16W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L180W100H135mm
T272	24°	1550-1700lm	24W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L260W100H135mm
T273	24°	820-980lm	12W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L130W130H155mm
T274	24°	1600-2040lm	24W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L239W130H155mm
T275	24°	2200-2700lm	36W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L349W130H155mm

TRIMLESS

T276	24°	460-550LM/W	8W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L155.5W83.5H134mm
T277	24°	1040-1250lm	16W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L235.5W83.5H134mm
T278	24°	1550-1700lm	24W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L315.5W83.5H134mm
T279	24°	820-980lm	12W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L185W113H154mm
T280	24°	1600-2040lm	24W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L294W113H154mm
T281	24°	2200-2700lm	36W	70LM/W	2700K,3000K,4000K,5000K	IP20	80	ON-OFF / DALI	L404W113H154mm

Show More Show Less

Additional information

CODE	T281
OPTIC	24°
LUMENS	2200-2700lm
WATTAGE	36W
LUMENS/W	70LM/W
COLOR	WHITE
IP RATING	IP20
CCT	2700K/3000K/4000K/5000K
CRI	80
CONTROL	ON-OFF / DALI
SIZE	L404W113H154mms
