FEATURES
– 110° wide beam angle
– Impact resistance rating: IK10 (20 joules of energy)
– Ingress protection rating: IP65
– Interchangeable CCT with slide switch
– Quick install with loop-in/out hole
– Replaceable driver for better maintenance
ApplicationS
It is designed for public ares such as stations, parks, pathways, driveways,underpasses, canopies and parking lots.
| CODE | OPTIC | LUMENS | WATTAGE | LUMENS/W | CCT | IP RATING | CRI | CONTROL | SIZE |
| K630 | 110° | 1500-1850lm | 18W | 90LM/W | 3000K / 4000K / 5000K / 5700K | IP65 | 80 | ON-OFF / DALI | Ø250*58 |
| K631 | 110° | 620-780lmn | 8W | 90LM/W | 3000K/4000K | IP65 | 80 | ON-OFF / DALI | Ø250*74 |
| K632 | 110° | 850-1030lm | 10W | 90LM/W | 3000K/4000K | IP65 | 80 | ON-OFF / DALI | Ø250*74 |
| K633 | 110° | 1045-1235lm | 12W | 90LM/W | 3000K/4000K | IP65 | 80 | ON-OFF / DALI | Ø250*74 |
| CODE | K630 |
|---|---|
| OPTIC | 110° |
| LUMENS | 1500-1850lm |
| WATTAGE | 18W |
| LUMENS/W | 90LM/W |
| COLOR | BLACK / WHITE |
| IP RATING | IP65 |
| CRI | 80 |
| CONTROL | ON-OFF / DALI |
| SIZE | Ø250*58 |
