FEATURES
– 110° wide beam angle
– Impact resistance rating: IK10 (20 joules of energy)
– Ingress protection rating: IP65
– Interchangeable CCT with slide switch
– Quick install with loop-in/out hole
– Replaceable driver for better maintenance
ApplicationS
It is designed for public areas such as stations, parks, pathways, driveways, underpasses, canopies, and parking lots.
The lamp body and base of this bulkhead are made of alloy ADC12, and the transparent impact-resistant PC cover can reach the protection of IK10(20 joules of energy). The lamp structure is a silicone ring with screws fixed to ensure the waterproof level of IP65.
| CODE | OPTIC | LUMENS | WATTAGE | LUMENS/W | CCT | IP RATING | CRI | CONTROL | SIZE |
| K630 | 110° | 1500-1850lm | 18W | 90LM/W | 3000K / 4000K / 5000K / 5700K | IP65 | 80 | ON-OFF / DALI | Ø250*58 |
| K631 | 110° | 620-780lmn | 8W | 90LM/W | 3000K/4000K | IP65 | 80 | ON-OFF / DALI | Ø250*74 |
| K632 | 110° | 850-1030lm | 10W | 90LM/W | 3000K/4000K | IP65 | 80 | ON-OFF / DALI | Ø250*74 |
| K633 | 110° | 1045-1235lm | 12W | 90LM/W | 3000K/4000K | IP65 | 80 | ON-OFF / DALI | Ø250*74 |
| CODE | K633 |
|---|---|
| OPTIC | 110° |
| LUMENS | 1045-1235lm |
| WATTAGE | 12W |
| LUMENS/W | 90LM/W |
| CCT | 3000K/4000K |
| COLOR | BLACK / WHITE |
| IP RATING | IP65 |
| CRI | 80 |
| CONTROL | ON-OFF / DALI |
| SIZE | Ø250*74 |
